SLAVE dimmer 230V 400VA 2M Next - 20168.N

Pdf
20168.N

Eikon Next / Devices / Electronic devices

SLAVE dimmer 230V 400VA 2M Next
SLAVE dimmer, 230 V~ for: 40-400 VA at 5 0Hz, 40-300 VA at 60 Hz dimmable electronic transformers, with neutral terminal, control from 20167 and 14167, MOSFET+TRIAC technology, protection fuse, Next - 2 modules

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Other
Type of load
Capacitive load
Applicable with button
No
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush mounted (plaster)
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
230,00 - 230,01 v
Frequency
50,00 - 60,00 HZ
Control voltage
230,00 - 230,01 v
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
42,00 mm
Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352388284
1 NR
6x5.4x5.3 [cm]
71.7 [g]
Barcode Qty 5 NR
8007352388291
5 NR
17.2x13.1x6 [cm]
414.7 [g]
