TV-RD-SAT single-conn.out.2outs whiteCode 20302.01.B

Download as PDFPDF
Immagine 20302.01.B
Immagine 20302.01.B
20302.01.B
Wiring devices / Traditional wiring devices / EIKON / Devices
TV-RD-SAT single-conn.out.2outs white
Coaxial TV-RD-SAT 5-2400 MHz socket outlet, single connection, demix, 2 outputs with male (TV-RD) and female F-type (SAT) connectors, connection attenuation 1 dB, white - 2 modules. Allows the passage of d.c. current and control signals (24 V 500 mA max) through the female connector
Product Status
3 - Active
Class group
Antenna and satellite technique
Class
Antenna socket box
Model
TWIN end socket
Tap loss at 860 MHz
1,00 dB
Tap loss at 2150 MHz
1,00 dB
Number of outlets
2
Suitable for remote power supply
Yes
Type of fastening
Snap mounting (engagement)
Colour
White
RAL-number (similar)
9016
Material
Plastic
Device width
44,90 mm
Device height
49,00 mm
Device depth
39,20 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352403048
1 NR
5.1x4.3x5.3 [cm]
80.3 [g]
Barcode Qty 5 NR
8007352403055
5 NR
14.4x11.6x6 [cm]
449.9 [g]
Barcode Qty 60 NR
8007352641945
60 NR
36.5x33x13.5 [cm]
5,790 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
