TV-RD-SAT through-line.out.2outs Next - 20302.10.N

20302.10.N
Wiring devices / Traditional wiring devices / EIKON / Devices

TV-RD-SAT through-line.out.2outs Next
Coaxial TV-RD-SAT 5-2400 MHz socket outlet, through-line, demix, 2 outputs with male (TV-RD) and female F-type (SAT) connectors, connection attenuation 10 dB, Next- 2 modules

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (905 kb)

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Antenna and satellite technique

Class
Antenna socket box

Model
TWIN end socket

Cover
None

Tap loss at 860 MHz
11,20 dB

Tap loss at 2150 MHz
12,00 dB

Number of outlets
2

Through loss at 860 MHz
2,00 dB

Through loss at 2150 MHz
2,80 dB

Suitable for remote power supply
No

Type of fastening
Snap mounting (engagement)

Colour
Silver

RAL-number (similar)
9022

Surface protection
Lacquered

Material
Plastic

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 5 NR

---

Barcode

8007352405561

1 NR

5.1x4.3x5.3 [cm]

79.3 [g]

8007352405578

5 NR

14.4x11.6x6 [cm]

449.3 [g]
