Vimar - 20322.N - RJ11 phone jack 6/4 +cover Next
Vimar - 20322.N - RJ11 phone jack 6/4 +cover Next
20322.N

Eikon Next / Devices / Phone socket outlets

RJ11 phone jack 6/4 +cover Next
RJ11 phone jack with dust cover, 6-position 4-conductor (6/4), screw terminals, Next

Product Status
3 - Active

Class group
Domestic switching devices
Class
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Utilization
UAE/IAE (ISDN)
Support ring
No
With dust cover
Yes
With hinged lid
No
With imprint
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Type of fastening
Clamp mounting
Number of modules (module system)
1
With strain relief
No
Luster terminal
No
Suitable for degree of protection (IP)
IP40
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
43,10 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352395404
1 NR
5.1x2.8x5.3 [cm]
21.7 [g]
Barcode Qty 10 NR
8007352395411
10 NR
14.4x11.6x6 [cm]
260.8 [g]
