BNC socket connector soldering white - 20361.B

Pdf
20361.B

Eikon white / Devices / EDP socket outlets

BNC socket connector soldering white
Bayonet type coaxial socket connector, jack BNC, for RG58, RG59/62, RX93 cables soldering, white

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Utilization
BNC/TNC
Support ring
No
With dust cover
No
With hinged lid
No
With imprint
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Transparent
No
Number of modules (module system)
1
With strain relief
No
Luster terminal
No
Suitable for degree of protection (IP)
IP20
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
31,20 mm

00. CE Marking - EU

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352313972
1 NR
5.1x2.8x5.3 [cm]
19.2 [g]
Barcode Qty 5 NR
8007352313989
5 NR
14.2x6.7x5.9 [cm]
126.2 [g]
