Power supply 32Vdc 100mA 1M white - 20580.B

20580.B

Eikon white / Systems / Stereophonic sound systems

Power supply 32Vdc 100mA 1M white
Supply unit with 32 V d.c. 100 mA output, supply voltage 110-230 V~ 50-60 Hz, white - 1 module

Product Status
4 - Active

Class group
Installation bus systems
Class
Power supply for bus system
Bus system KNX
No
Bus system KNX radio
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Mounting method
Flush mounted (plaster)
Width in number of modular spa
1
With LED indication
No
Bus voltage stockable
No
Number of lines to feed
1
Max. output current
100,00 mA
Minimum order quantity: 1 NR

Barcode

8007352400542
1 NR
5.1x4.3x5.3 [cm]
49.49 [g]
8007352400559
5 NR
14.4x11.6x6 [cm]
296.79 [g]
Question: What is the item 20580 used for?
Answer: The 20580 power supply can power the flush mounted amplifier part no. 20581 without burdening the main BUS 01801 power supply.

Didn't find the answer you were looking for?

Ask a question

Share

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
