20593.N

Eikon Next / Devices / Radiofrequency

16 A IoT connected actuator Next
View Wireless connected electronic control device with NO 16 A 100-240 V~ 50/60 Hz relay output, local control with push button or remote control, double technology with Bluetooth® wireless technology 5.0 standard for the realization of View Wireless mesh system and Zigbee 3.0 standard, function for measuringthe instant power and load cut-off threshold, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, Next

  • Configuration from View Wireless App for Bluetooth technology system and Amazon App for Zigbee technology
  • Compatible with Alexa, Google Home and IFTTT, using the dedicated gateway or Zigbee hub

Product Status
3 - Active

You may also be interested in

Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX radio
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequent bidirectional
Yes
Mounting method
Flush mounted (plaster)
Width in number of modular spacings
1
Local operation/hand operation
Yes
With LED indication
Yes
Suitable for C-load
Yes
Max. number of switching contacts
1
Rated current
16 A
Rated operating voltage
100,00 - 240,00 v
Different phases connectable
No
Bus connection included
Yes
Modular expandability
No
Degree of protection (IP)
IP40
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352628526
1 NR
6x5.4x5.2 [cm]
59 [g]
Barcode Qty 60 NR
8007352628533
60 NR
37.5x30x13.5 [cm]
3,900 [g]
Question: Which function envisages the actuator device art.14593-19593-20593-16593, configured in energy monitoring mode?
Answer: The product allows the display of the energy consumed and the disconnection upon exceeding a given threshold which can be set by the user.
Question: How many Energy meters art.02963 can I install in a Wireless system?
Answer: Each connected system allows a maximum of 2 meters art.02963.
Question: Can the connected 2-way switch art.14592-19492-19592-20592 be used as a 1-way switch for a controlled socket outlet
Answer: No, as a minimum load of 2W is necessary for correct operation. To manage a controlled socket outlet, you can use art. 14593-16493-19593-20593 or art. 03981
