Plate 3Mx3 Vintage anthracite grey - 22673.3.03

Pdf
22673.3.03

Eikon EXÉ / Cover plates / Vintage and Flat metal cover plate

Plate 3Mx3 Vintage anthracite grey
Plate 3Mx3 Vintage anthracite grey

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
3
Mounting direction
Horizontal and vertical
Number of units horizontal
3
Number of units vertical
1
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
Number of gangs
0
With mounting grid
Yes
Suitable for flush-mounted installation
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (akin)
7043
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
122,00 mm
Height
90,00 mm
Depth
7,15 mm
Built-in width
122,00 mm
Built-in height
90,00 mm
Diameter bore hole (opening)
0 mm
Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352621749
1 NR
12.5x9.5x1.4 [cm]
212.6 [g]
Barcode Qty 5 NR
8007352621756
5 NR
13.5x8x10.4 [cm]
1,114.4 [g]
