Plate 5Mx5 BS Flat gold - 22689.5.82

Pdf
22689.5.82

Eikon EXÉ / Cover plates / Vintage and Flat metal cover plate

Plate 5Mx5 BS Flat gold
5-module cover plate for five Flat controls, metal, gold

Product Status
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
5
Mounting direction
Horizontal and vertical
Number of units horizontal
5
Number of units vertical
1
Number of modules horizontal (module system)
5
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for flush-mounted installation
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Surface protection
Metallic
Surface finishing
Glossy
Colour
Gold
RAL-number (akin)
1036
Transparent
No
With hinged lid
Yes
Type of fastening
Clamp mounting
Width
159,30 mm
Height
90,00 mm
Depth
7,15 mm
Built-in width
159,30 mm
Diameter bore hole (opening)
0 mm
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352656451
1 NR
16.5x9.5x1.4 [cm]
216 [g]
Barcode Qty 5 NR
8007352656468
5 NR
17.5x8x10.4 [cm]
1,145.4 [g]
