Plate 5Mx10 BS Flat brushed nickel - 22699.11

Pdf

22699.11
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Plate 5Mx10 BS Flat brushed nickel
5-module BS cover plate for ten Flat controls, metal, brushed nickel

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
10
Mounting direction
Horizontal and vertical
Number of units horizontal
5
Number of units vertical
2
Number of modules horizontal (module system)
5
Number of modules vertical (module system)
2
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Surface protection
Metallic
Surface finishing
Matt
Colour
Stainless steel
RAL-number (similar)
7048
Transparent
No
With hinged lid
Yes
Type of fastening
Clamp mounting
Width
159,30 mm
Height
90,00 mm
Depth
7,15 mm
Built-in width
159,30 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352656574
1 NR
16.5x9.5x1.4 [cm]
216 [g]
Barcode Qty 5 NR
8007352656581
5 NR
17.5x8x10.4 [cm]
1,145.4 [g]
