30300.10B
Wiring devices / Traditional wiring devices / LINEA / Devices
TV-RD-SAT through-line out.white
TV-RD-SAT coaxial socket outlet, 5-2400 Mhz, feed-through, with male connector, 10 dB connection attenuation, white
Product Status
3 - Active
Drawings
Class group
Antenna and satellite technique
Antenna and satellite technique
Class
Antenna socket box
Antenna socket box
Model
Loop-through socket
Loop-through socket
Type of socket outlet
TV/RD/SAT
TV/RD/SAT
Mounting method
Flush-mounted
Flush-mounted
Number of modules (module system)
1
1
Cover
None
None
Tap loss at 860 MHz
10,60 dB
10,60 dB
Tap loss at 2150 MHz
9,90 dB
9,90 dB
Number of outlets
1
1
Suitable for cable modem
No
No
Through loss at 860 MHz
2,20 dB
2,20 dB
Through loss at 2150 MHz
3,40 dB
3,40 dB
TV frequency band
5 - 2.400 MHz
5 - 2.400 MHz
Suitable for remote power supply
Yes
Yes
Radio frequency band
5 - 2.400 MHz
5 - 2.400 MHz
SAT frequency band
5 - 2.400 MHz
5 - 2.400 MHz
Shielding efficiency class
Class A
Class A
Type of fastening
Snap mounting (engagement)
Snap mounting (engagement)
Colour
White
White
RAL-number (similar)
9016
9016
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Anti-bacterial treatment
No
No
Degree of protection (IP)
IP20
IP20
Device width
2.230,00 mm
2.230,00 mm
Device height
5.280,00 mm
5.280,00 mm
Device depth
3.190,00 mm
3.190,00 mm
Minimum order quantity: 20 NR
Barcode
8007352680050
1 NR
3.6x2.7x5.6 [cm]
51.04 [g]
8007352680067
20 NR
19.4x12.6x6.5 [cm]
1,095 [g]
8007352694491
200 NR
40x33.5x15 [cm]
11,352 [g]
