Flush consumer unit 8M Idea grey - V53008.G

Pdf
Vimar - V53008.G - Flush consumer unit 8M Idea grey
Vimar - V53008.G - Flush consumer unit 8M Idea grey

V53008.G
System infrastructure / Enclosures and control units / Switchboards / Flush mounting

Flush consumer unit 8M Idea grey
Flush consumer unit with horizontally hinged transparent door, 8 modules, delivered with DIN (60715 TH35) rail, Idea grey

Product Status
2 - Will be discontinued

Class group
Distribution boards
Class
Small distribution board
Mounting method
Flush-mounted
Number of rows
1
Width in number of modular spacings
8
Type of covering
Door
Transparent cover/door
Yes
With lock
No
Housing material
Plastic
DIN-rail
Yes
With mounting plate
No
Extension possible
No
EMC-version
No
Colour
Grey
RAL-number
0
Degree of protection (IP)
IP40
Height
176,00 mm
Width
230,00 mm
Depth
18,00 mm
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352081918
1 NR
28.4x18.4x7.5 [cm]
356.87 [g]
Barcode Qty 14 NR
8007352470811
14 NR
58x38.5x30 [cm]
5,746.18 [g]
