TV-RD-SAT through-line male outlet10dB i - 06456.10

06456.10
Wiring devices / Traditional wiring devices / MASCOT / Devices

TV-RD-SAT through-line male outlet10dB i
Coaxial TV-RD-SAT 5-2400 MHz socket outlet, through-line, with IEC 60169-2 male connector, connection attenuation 10 dB, ivory

Product Status
2 - Will be discontinued

You may also be interested in

V71001.AU - Flush mounting box ø 60mm light black

V71001 - Flush mounting box ø 60mm light blue

V71701 - Round flush-mount box f/hollow wall blue

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Antenna and satellite technique

Class
Antenna socket box

Model
Loop-through socket

Cover
None

Tap loss at 860 MHz
10,60 dB

Tap loss at 2150 MHz
9,90 dB

Number of outlets
1

Through loss at 860 MHz
2,20 dB

Through loss at 2150 MHz
3,40 dB

Suitable for remote power supply
No

Type of fastening
Snap mounting (engagement)

Colour
Beige

RAL-number (similar)
9001

Material
Plastic

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 5 NR

---

Barcode

8007352101722

1 NR

8x8x3.6 [cm]

90.6 [g]

8007352104785

5 NR

15.9x11.4x8.9 [cm]

518.1 [g]
