Dimmer 120V 30-500W/30-300VA carbon - 09147.CM

09147.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Dimmer 120V 30-500W/30-300VA carbon
120 V~ 50-60 Hz dimmer for: 30-500 W incandescent lamps and 30-300 VA ferromagnetic transformers, control and adjustment with rotary potentiometer, visible in darkness, carbon matt

Product Status
3 - Active

You may also be interested in

09135.1.120.CM - Dimmer MASTER 120V universal carbon matt

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (479 kb)

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Push button

Method of operation
Push button

Nominal voltage
120 V

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Anti-bacterial treatment
No

Surface protection
Lacquered

Surface finishing
Matt

Colour
Anthracite

RAL-number (similar)
7016

Transparent
No

Label space/information surface
Yes

Device width
22,30 mm

Device height
47,00 mm

Device depth
55,50 mm

00. CE Marking - EU

29. QCERT - Colombia

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

Minimum order quantity: 10 NR

---

Barcode

8007352666351

1 NR

6x2.8x5.3 [cm]

43.2 [g]

8007352666368

10 NR

14.4x13.1x6 [cm]

477.8 [g]

8007352666375

200 NR

50.5x20x28 [cm]

9,998 [g]
