16 A IoT connected actuator carbon matt - 09593.CM

Pdf

09593.CM
Wiring devices / View Wireless wiring devices / NEVE UP / Devices

16 A IoT connected actuator carbon matt
View Wireless connected electronic control device with NO 16(3,5)A 100-240 V~ 50/60 Hz relay output, local control with push button or remote control, double technology with Bluetooth® wireless technology 5.0 standard for the realization of View Wireless mesh system and Zigbee 3.0 standard, function for measuringthe instant power and load cut-off threshold, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, carbon matt

Product Status
3 - Active

Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
Yes
Mounting method
Flush-mounted
Width in number of modular spacings
0
Local operation/hand operation
Yes
With LED indication
Yes
Number of digital inputs
0
Max. switching power
0 W
Max. switching power LED
0 W
Output power
0 W
Suitable for C-load
No
Max. number of switching contacts
1
Max. switching current
16 A
Rated current
16 A
Rated operating voltage
100,00 - 240,00 V
Different phases connectable
No
With bus connection
No
Bus module detachable
No
Modular expandability
No
Degree of protection (IP)
IP40

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352732261
1 NR
5.2x3.5x5.3 [cm]
53.6 [g]
Barcode Qty 60 NR
8007352732278
60 NR
27x23x12.5 [cm]
3,414 [g]
