0K21666.71.03
Smart systems&products / KNX / EIKON / Cover plates
Plate 3M transp.NR crystal aqua IP55
3-module vertical electronic cover plate for IP55 vertical external transponder reader, door bell function not active, complete with IP55 mounting frame, to be completed with room number labels 21846, plate glass, aqua
Product Status
3 - Active
You may also be interested in
Class group
Domestic switching devices
Domestic switching devices
Class
Cover frame for domestic switching devices
Cover frame for domestic switching devices
Number of units
3
3
Mounting direction
Vertical
Vertical
Number of device inserts horizontal
1
1
Number of device inserts vertical
3
3
Number of modules horizontal (module system)
3
3
Number of modules vertical (module system)
1
1
With mounting grid
Yes
Yes
Suitable for subfloor installation duct box
Yes
Yes
Suitable for wall duct
Yes
Yes
Suitable for built-in installation
No
No
Label space/information surface
Yes
Yes
Material
Glass
Glass
Material quality
Acrylic glass
Acrylic glass
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Glossy
Glossy
Colour
White
White
RAL-number (similar)
9018
9018
Transparent
No
No
With hinged lid
No
No
Degree of protection (IP)
IP55
IP55
Type of fastening
Clamp mounting
Clamp mounting
Width
111,50 mm
111,50 mm
Height
123,50 mm
123,50 mm
Depth
11,300 mm
11,300 mm
Built-in width
49,90 mm
49,90 mm
Diameter bore hole (opening)
0,00 mm
0,00 mm
Minimum order quantity: 1 NR
Barcode
8007352692015
1 NR
15.5x17.3x4.7 [cm]
335 [g]
