RGB dimmer 120V grey - 19138.120

Pdf
19138.120

Arké / Devices / Electronic devices

RGB dimmer 120V grey
RGB dimmer 120 V~ 60 Hz for: RGB LED lamps, electronic RGB LED supply units, ON/OFF control und brightness adjustment with built-in push button or from peripheral NO push buttons, colour adjustment with rotary potentiometer, visible in darkness, grey. Not for Isoset enclosures

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Turn button
Type of load
Other
Applicable with button
Yes
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush mounted (plaster)
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
120,00 - 120,01 v
Frequency
60,00 - 60,01 HZ
Control voltage
120,00 - 120,01 v
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
61,40 mm

00. CE Marking - EU

19. NOM - Mexico

37. Marking - Morocco

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352497962
1 NR
5.2x3.9x6.2 [cm]
59.9 [g]
Barcode Qty 5 NR
8007352497979
5 NR
14.4x11.6x6 [cm]
342.4 [g]
