Plate 3M BS wood Italian walnut - 21648.31

Pdf
Vimar - 21648.31 - Plate 3M BS wood Italian walnut
Vimar - 21648.31 - Plate 3M BS wood Italian walnut
21648.31

Eikon EVO / Cover plates / Wooden cover plates

Plate 3M BS wood Italian walnut
3-module cover plate for British standard mounting, solid wood, Italian walnut

Product Status
3 - Active

You may also be interested in

20608
20608 - Frame 3M BS

Drawings

view encumbered art. 21648.31
PNG DXF
rear view art. 21648.31
PNG DXF
3D view art. 21648.31
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
3
Mounting direction
Horizontal and vertical
Number of units horizontal
3
Number of units vertical
1
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Wood
Material quality
Other
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Wood
RAL-number (similar)
8025
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
95,40 mm
Height
95,40 mm
Depth
9,80 mm
Built-in width
95,40 mm
Built-in height
95,40 mm
Diameter bore hole (opening)
0 mm

01. IMQ - Italy

08. ASTA - UK

29. QCERT - Colombia

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352488397
1 NR
13.1x11.6x1.85 [cm]
56.4 [g]
Barcode Qty 5 NR
8007352488403
5 NR
13.9x10.8x12.6 [cm]
338.4 [g]
