Plate 2Mx2 Vintage gold - 22672.2.82

Pdf
Vimar - 22672.2.82 - Plate 2Mx2 Vintage gold
Vimar - 22672.2.82 - Plate 2Mx2 Vintage gold
22672.2.82

Eikon EXÉ / Cover plates / Vintage and Flat metal cover plate

Plate 2Mx2 Vintage gold
Plate 2Mx2 Vintage gold

Product Status
3 - Active

Drawings

view encumbered art. 22672.2.82
PNG DXF
rear view art. 22672.2.82
PNG DXF
3D view art. 22672.2.82
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
2
Mounting direction
Horizontal and vertical
Number of units horizontal
2
Number of units vertical
1
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Gold
RAL-number (similar)
1036
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
90,00 mm
Height
90,00 mm
Depth
7,15 mm
Built-in width
90,00 mm
Built-in height
90,00 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

01. IMQ - Italy

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352621985
1 NR
9.5x9.5x1.4 [cm]
161.8 [g]
Barcode Qty 5 NR
8007352621992
5 NR
10.3x8x10.4 [cm]
855.2 [g]
