IoT connected radar sensor 1M Canvas - 30179.C

Pdf
Vimar - 30179.C - IoT connected radar sensor 1M Canvas
Vimar - 30179.C - IoT connected radar sensor 1M Canvas

30179.C
Wiring devices / View Wireless wiring devices / LINEA / Devices

IoT connected radar sensor 1M Canvas
UWB radar sensor, IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system, 1 solid state output for extra low voltage controls (SELV and non SELV), 1 input for external push button for output activation or to recall a scenario, 100-240 V 50/60 Hz power supply, canvas

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Other
Method of operation
Other
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
No
Number of rockers
0
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
7032
Label space/information surface
No
Illumination
No
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
240 V
Rated current
0,40 A
Switching current for fluorescent lamps
0
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Device width
22,20 mm
Device height
52,80 mm
Device depth
49,70 mm
Built-in depth
43,30 mm
Compatible with Apple HomeKit
Yes
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
IFTTT support available
No

00. CE Marking - EU

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

40. Bluetooth technology

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352715677
1 NR
6x4.5x5.4 [cm]
49 [g]
Barcode Qty 10 NR
8007352715684
10 NR
23.5x12.5x6.5 [cm]
571.2 [g]
