30653.22
Wiring devices / Traditional wiring devices / LINEA / Cover plates
Plate 3M varn.techno Metal
3-module cover plate, painted technopolymer, Metal
Product Status
3 - Active
You may also be interested in
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Cover frame for domestic switching devices
Cover frame for domestic switching devices
Number of units
3
3
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of units horizontal
3
3
Number of units vertical
1
1
Number of modules horizontal (module system)
3
3
Number of modules vertical (module system)
1
1
With mounting grid
Yes
Yes
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
Yes
Yes
Suitable for wall duct
Yes
Yes
Suitable for built-in installation
Yes
Yes
Label space/information surface
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Anti-bacterial treatment
No
No
Surface protection
Lacquered
Lacquered
Surface finishing
Matt
Matt
Colour
Aluminium
Aluminium
RAL-number (similar)
9007
9007
Transparent
No
No
With hinged lid
No
No
Degree of protection (IP)
IP00
IP00
Type of fastening
Engage (snap)
Engage (snap)
Width
122,80 mm
122,80 mm
Height
88,00 mm
88,00 mm
Depth
10,40 mm
10,40 mm
Built-in width
122,80 mm
122,80 mm
Built-in height
4,70 mm
4,70 mm
Diameter bore hole (opening)
0 mm
0 mm
00. CE Marking - EU
Minimum order quantity: 10 NR
Barcode
8007352687349
1 NR
9.7x18.5x0.9 [cm]
20 [g]
8007352687356
10 NR
19x11.5x10.5 [cm]
290 [g]
8007352687363
100 NR
56.5x25x21.5 [cm]
3,345 [g]
