EKKO 300D linear kit 24V 3m 300kg - EK06.EXP

EK06.EXP
Safety / ELVOX Automations / Kits / Hinged

EKKO 300D linear kit 24V 3m 300kg
Kit EKKO 300D for swing gates with leave

Product Status
3 - Active

Kit components

EAM2 - EKKO 300D linear operator 24V 3m 300kg

ECA5 - 24V control panel for EKKO operators

ELA5 - Flashing light LED 12/24Vdc

ETRN2 - 2-channel remote control 433MHz rolling

EFA1 - Pair of 12/24V 110mA 180° photocells 15m

ZX20 - Warning sign

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (805 kb)
• Quick Guide (1878 kb)
• Manuale installatore (1333 kb)
• Manuel installateur (1340 kb)
• Manual del instalador (1335 kb)
• Installer manual (1306 kb)
• Εγχειρίδιο τεχνικού εγκατάστασης (1279 kb)
• Installationsanleitung (1356 kb)
• Installer manual (1763 kb)

Class group
Gate operators, pumps and ventilators

Class
Swing gate operator

Model
2 wings

Max. width of door/gate wing
3.000 mm

Max. weight of door/gate leaf
800 kg

Drive principle
Electromechanical

Type of current
DC

Motor voltage
24 V

Limit switch
Gate stop

Soft run
Yes

Automatic closing
Yes

Frequency radio receiver
433 MHz

With manual transmitter
Yes

With motor control unit
Yes

With post fittings
Yes

With wing fittings
Yes

With key-switch
No

With radio receiver
Yes

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8013406231031

1 NR

86x30x32 [cm]

23,174 [g]
