TV IEC single connection outlet carbon m - 09313.CM

Pdf
Vimar - 09313.CM - TV IEC single connection outlet carbon m
Vimar - 09313.CM - TV IEC single connection outlet carbon m

09313.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

TV IEC single connection outlet carbon m
TV coaxial socket outlet, 40-862 MHz, simple, with female connector IEC 60169-2, carbon matt

Product Status
3 - Active

You may also be interested in

09300.01.CM
09300.01.CM - TV-RD-SAT single conn.male outlet carbon
09300.10.CM
09300.10.CM - TV-RD-SAT through-line male outlet carbo
09303.CM
09303.CM - TV-FM-SAT single conn. 3outs carbon matt
09318.CM
09318.CM - F-type TV outlet carbon matt
09302.01.CM
09302.01.CM - TV-RD-SAT single conn.outlet 2outs carbo

Drawings

view encumbered art. 09313.CM
PNG DXF
3D view art. 09313.CM
PNG DXF
Class group
Antenna and satellite technique
Class
Antenna socket box
Model
End socket
Mounting method
Flush-mounted
Cover
None
Suitable for remote power supply
Yes
Colour
Anthracite
RAL-number (similar)
7016
Surface protection
Lacquered
Surface finishing
Matt
Material
Plastic
Material quality
Thermoplastic

10. EAC Eurasian Customs Union

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352666870
1 NR
4.1x2.8x5.3 [cm]
23.6 [g]
Barcode Qty 10 NR
8007352666887
10 NR
14.4x9x6 [cm]
274.2 [g]
Barcode Qty 160 NR
8007352666894
160 NR
37.5x30x13.5 [cm]
4,704 [g]
