Button 1M for RF switch white - 2pieces - 09506

Pdf
Vimar - 09506 - Button 1M for RF switch white - 2pieces
Vimar - 09506 - Button 1M for RF switch white - 2pieces

09506
Smart systems&products / Smart switch&sound / NEVE UP / Buttons

Button 1M for RF switch white - 2pieces

Product Status
3 - Active

Drawings

view encumbered art. 09506
PNG DXF
rear view art. 09506
PNG DXF
3D view art. 09506
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
One-part button
Imprint/indication
None
Scannable symbol/barrier free
No
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Engage (snap)
Monitoring window/light outlet
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Anti-bacterial treatment
No
Colour
White
RAL-number (similar)
9003
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP40
Width
22,30 mm
Height
44,35 mm
Depth
7,00 mm

00. CE Marking - EU

43. UKCA mark - Great Britain

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352732704
1 NR
2.2x4.4x0.6 [cm]
6.3 [g]
Barcode Qty 10 NR
8007352732711
10 NR
12.3x9.6x5.1 [cm]
94.2 [g]
