Plate 4M (2+2)x71 techn.matt silver - 09664.21

Pdf
Vimar - 09664.21 - Plate 4M (2+2)x71 techn.matt silver
Vimar - 09664.21 - Plate 4M (2+2)x71 techn.matt silver

09664.21
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 4M (2+2)x71 techn.matt silver
4-module cover plate (2+2, distance between centres 71 mm), technopolymer, matt silver

Product Status
3 - Active

You may also be interested in

09602.1
09602.1 - Frame 2M +claws 71mm
09603.1
09603.1 - Frame 2M wihtout screws 71mm

Drawings

view encumbered art. 09664.21
PNG DXF
3D view art. 09664.21
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
4
Mounting direction
Horizontal and vertical
Number of units horizontal
2
Number of units vertical
1
Number of modules horizontal (module system)
4
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9006
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
157,00 mm
Height
86,00 mm
Depth
8,50 mm
Built-in width
157,00 mm

00. CE Marking - EU

29. QCERT - Colombia

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352660304
1 NR
18x9x0.5 [cm]
20.87 [g]
Barcode Qty 5 NR
8007352660311
5 NR
10x4.5x21 [cm]
164.27 [g]
Barcode Qty 160 NR
8007352706088
160 NR
57.5x22.5x30 [cm]
5,256.64 [g]
