Four half-buttons 1M I/O symbols Silver - 14841.2.SL

Pdf
Vimar - 14841.2.SL - Four half-buttons 1M I/O symbols Silver
Vimar - 14841.2.SL - Four half-buttons 1M I/O symbols Silver

14841.2.SL
Smart systems&products / KNX / PLANA / Buttons

Four half-buttons 1M I/O symbols Silver
Four interchangeable half-buttons, 1 module, I O symbol, Silver

Product Status
2 - Will be discontinued

Alternative products

14751.1.SL
14751.1.SL - 2 half buttons 1M ON/OFF symbol Silver
14751.4.SL
14751.4.SL - 2 half buttons 1M ON/OFF vol.symb.Silver

Drawings

view encumbered art. 14841.2.SL
PNG DXF
rear view art. 14841.2.SL
PNG DXF
3D view art. 14841.2.SL
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
Other
Imprint/indication
Characters 0 and 1
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Clamp mounting
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
9006
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP40
Depth
650,00 mm

96. Electrotechnical expert

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352383937
1 NR
7x5.5x0.6 [cm]
6.3 [g]
Barcode Qty 6 NR
8007352383944
6 NR
14.2x6.7x5.9 [cm]
68.87 [g]
