Classica plate 2Mpan metal brush-nickel - 16782.34

Pdf

16782.34
Wiring devices / Traditional wiring devices / IDEA / Cover plates

Classica plate 2Mpan metal brush-nickel
2-module Classica cover plate, die-cast metal, for panel mounting, brushed nickel

Product Status
3 - Active

You may also be interested in

Drawings

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
2
Mounting direction
Horizontal and vertical
Number of units horizontal
1
Number of units vertical
2
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
2
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Halogen free
Yes
Surface protection
Metallic
Surface finishing
Glossy
Colour
Titanium
RAL-number (similar)
7048
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
40,00 mm
Height
136,00 mm
Depth
9,00 mm
Built-in width
40,00 mm
Built-in height
136,00 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

43. UKCA mark - Great Britain

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352151291
1 NR
14.3x4.3x1.1 [cm]
69.2 [g]
Barcode Qty 10 NR
8007352151307
10 NR
14.4x11.6x6 [cm]
723.67 [g]
