16787.15
Wiring devices / Traditional wiring devices / IDEA / Cover plates
Classica plate 2Mpan techn.graph.grey
2-module Classica cover plate, technopolymer, for panel mounting, graphite grey
Product Status
3 - Active
You may also be interested in
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Cover frame for domestic switching devices
Cover frame for domestic switching devices
Number of units
2
2
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of units horizontal
1
1
Number of units vertical
2
2
Number of modules horizontal (module system)
1
1
Number of modules vertical (module system)
2
2
With mounting grid
Yes
Yes
Suitable for subfloor installation duct box
Yes
Yes
Suitable for wall duct
Yes
Yes
Suitable for built-in installation
Yes
Yes
Label space/information surface
Yes
Yes
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Glossy
Glossy
Colour
Anthracite
Anthracite
RAL-number (similar)
7043
7043
Transparent
No
No
With hinged lid
No
No
Degree of protection (IP)
IP00
IP00
Type of fastening
Clamp mounting
Clamp mounting
Width
40,00 mm
40,00 mm
Height
136,00 mm
136,00 mm
Depth
9,00 mm
9,00 mm
Built-in width
40,00 mm
40,00 mm
Built-in height
136,00 mm
136,00 mm
Diameter bore hole (opening)
0 mm
0 mm
00. CE Marking - EU
Minimum order quantity: 1 NR
Barcode
8007352081109
1 NR
4x13.6x0.9 [cm]
12.73 [g]
8007352081116
10 NR
14.4x9x6 [cm]
161.93 [g]
