IoT connected RFID reader white - 30812.B

Pdf
Vimar - 30812.B - IoT connected RFID reader white
Vimar - 30812.B - IoT connected RFID reader white

30812.B
Wiring devices / View Wireless wiring devices / LINEA / Devices

IoT connected RFID reader white
RFID smart card landing reader, card configuration using VIEW Wireless App, Bluetooth technology standard, IoT technology on Bluetooth technology 5.0 standard for the creation of VIEW Wireless mesh system, 1 relay output NO 16 A 100-240 V~, 1 DND input, LED with brightness control, 100-240 V~ 50/60 Hz power supply, white - 2 modules

Product Status
3 - Active

Class group
Alarm installations, emergency call and signalling
Class
Access control system
Standalone
No
Networkable
Yes
PC-binding
No
Type of interface
Other
Reading strategy
Code
Signalling
Light signal
Mounting method
Flush-mounted
Operating voltage AC 50 Hz
100,00 - 240,00 V
Operating voltage AC 60 Hz
100,00 - 240,00 V
Operating temperature
5 - 45 °C
Degree of protection (IP)
IP20
Colour
White
Model
Reader
Material
Plastic
Power over Ethernet (PoE)
None
Width
44,80 mm
Height
52,80 mm
Depth
40,30 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
VdS class
None

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352675315
1 NR
6x5.4x5.2 [cm]
71 [g]
Barcode Qty 10 NR
8007352675322
10 NR
28.1x13.1x6 [cm]
797.4 [g]
Barcode Qty 120 NR
8007352675339
120 NR
38.5x29x30 [cm]
10,010 [g]
