2P+E 16A P17/11 outlet red - 09203.R

Pdf
Vimar - 09203.R - 2P+E 16A P17/11 outlet red
Vimar - 09203.R - 2P+E 16A P17/11 outlet red
09203.R

Neve Up / Devices / Socket outlets for dedicated lines

2P+E 16A P17/11 outlet red
SICURY 2P+T 16 A 250 V~ socket outlet, Italian standard type P17/11, red

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type Bipasso
With built-in USB power supply
No
Number of modules (module system)
1
With hinged lid
No
Label space/information surface
Yes
Colour
Red
RAL-number (similar)
3001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Anti-bacterial treatment
No
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Width of device
22,30 mm
Height of device
47,00 mm
Depth of device
32,70 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

19. NOM - Mexico

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352664401
1 NR
4.1x2.8x5.3 [cm]
28.07 [g]
Barcode Qty 50 NR
8007352664418
50 NR
21.4x11.6x14.2 [cm]
1,495.07 [g]
Barcode Qty 500 NR
8007352664425
500 NR
57.5x22.5x30 [cm]
15,387.33 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
